Description
Laboratory ring and puck mill and pulverizer, also known as a shatterbox
Compact design, easy and safe to operate
Ideal for wet and dry grinding and crushing various samples
High efficiency for rock, ore, minerals, soil and others
High energy input through 3D movements of the grinding ring and puck
Digital timing device with safety protection
Grinding process programmable
Speed: 1750RPM, programmable
Feeding size: <15mm
Grinding results: <38µm (200mesh)
Grinding container 1xD200/250mL or 1xD200/4x50mL or 3xD100/100mL
Container materials Hardened steel/alloy or tungsten carbide
AC motor 250W, VFD control
4.3 inch touch screen controller
Grinding time and speed programmable
Run/Stop time 0-999min per cycle, up to 999 cycles
Power supply AC115/230V single phase (as marked)
Product dimensions 60x50x60 cm, weight 80kg/175lbs.
Compact design, easy and safe to operate
Ideal for wet and dry grinding and crushing various samples
High efficiency for rock, ore, minerals, soil and others
High energy input through 3D movements of the grinding ring and puck
Digital timing device with safety protection
Grinding process programmable
Speed: 1750RPM, programmable
Feeding size: <15mm
Grinding results: <38µm (200mesh)
Grinding container 1xD200/250mL or 1xD200/4x50mL or 3xD100/100mL
Container materials Hardened steel/alloy or tungsten carbide
AC motor 250W, VFD control
4.3 inch touch screen controller
Grinding time and speed programmable
Run/Stop time 0-999min per cycle, up to 999 cycles
Power supply AC115/230V single phase (as marked)
Product dimensions 60x50x60 cm, weight 80kg/175lbs.
