Description
High precision recirculating chiller
Stainless steel tank, seamless welding, leakage tested
Liquid level sensor switch for shutoff protection
Lowest temperature -20 ℃ or -40 ℃
Brushless DC motor driven pump, long lasting
Pump speed 20L/min
Connector D12 barbed type
Excellent insulation to prevent heat and improve energy efficiency
PID temperature controller with PT-100 RTD sensor
7-inch touch screen control panel
Built-in over-temperature protection
One-year standard warranty
Cooling Capacity/Refrigerating Watts:
*** Data provided by compressor manufacturer, not measured by VivTek ***
Stainless steel tank, seamless welding, leakage tested
Liquid level sensor switch for shutoff protection
Lowest temperature -20 ℃ or -40 ℃
Brushless DC motor driven pump, long lasting
Pump speed 20L/min
Connector D12 barbed type
Excellent insulation to prevent heat and improve energy efficiency
PID temperature controller with PT-100 RTD sensor
7-inch touch screen control panel
Built-in over-temperature protection
One-year standard warranty
| Model | Tank |
Compressor |
Cover/Lid |
Amp AC115/230V |
| LBC-C2010 | 10L |
805W/R404a | D15cm/6inch |
8A/4A |
| LBC-C2020 | 20L |
935W/R404a |
D15cm/6inch |
9A/5A |
| LBC-C2030 | 30L |
1250W/R404a |
D15cm/6inch |
---/7A |
| LBC-C4010 | 10L | 700W/R404a |
D15cm/6inch |
8A/4A |
| LBC-C4020 | 20L |
1500W/R404a |
D15cm/6inch |
---/8A |
| LBC-C4030 | 30L | 2080W/R404a |
D15cm/6inch |
---/15A |
Cooling Capacity/Refrigerating Watts:
*** Data provided by compressor manufacturer, not measured by VivTek ***
| Model | -40 ℃ | -20 ℃ |
-10 ℃ | 0 ℃ |
10 ℃ | 20 ℃ |
| LBC-C2010 | --- |
1150W | 1750W | 2.4KW | 3.4KW | 4.3KW |
| LBC-C2020 | --- |
1390W | 1980W | 2.9W | 3.9W | 5.2KW |
| LBC-C2030 | --- | 1450W | 2500W | 3.5W | 5.0W | 6.7W |
| LBC-C4010 | 350W | 1250W |
1950W | 2.8W | 3.1W | 3.9W |
| LBC-C4020 | 600W |
2150W | 3000W | 4.5W | 5.8W | 8.0W |
| LBC-C4030 | 1000W |
3300W | 4500W | 6.2W | 8.8W | 12KW |
